Solenoid Controlled Diesel Fuel Injection Pumps

MODEL DE ELECTRONICALLY CONTROLLED PUMP

The DE10 is a full authority electronically controlled fuel injection pump for off-highway industrial and agricultural engine applications. Precise electronic pulses fed to a solenoid operated spill valve manage fuel delivery and timing control. The DE10 was introduced in 2002 on four and six cylinder engine applications up to ratings of 130kW and this electronically controlled pump has proven to be a reliable and cost effective fuel pump. Stanadyne has developed a new pilot injection control strategy to assist the engine manufacturer in achieving the latest emission requirements.

FEATURES

• Capacities to 25 kW (34 BHP) per cylinder
• Peak injection pressures to 900 bar (13,000 PSI)
• 3, 4 and 6 cylinder versions
• Electronic spill control with single 12-volt solenoid actuator for timing and fuel control
• Two pumping plungers driven by internal cam ring
• Angle-based control strategy
• Engine speeds to 2800 RPM

OPTIONS

• Pump mounted solenoid driver with poppet valve closure detection
• Complete flexibility of fuel metering and injection timing
• Complete governing flexibility with enhanced idle speed control
• Pilot injection control strategy
